Thermostatic Mixing Valve Nickel DN20/DN25 Hot And Cold Water Temperature Regulation Hot Water Circulation
Thermostatic Mixing Valve Nickel DN20/DN25 Hot And Cold Water Temperature Regulation Hot Water Circulation
Thermostatic Mixing Valve Nickel DN20/DN25 Hot And Cold Water Temperature Regulation Hot Water Circulation
Thermostatic Mixing Valve Nickel DN20/DN25 Hot And Cold Water Temperature Regulation Hot Water Circulation
  • Load image into Gallery viewer, Thermostatic Mixing Valve Nickel DN20/DN25 Hot And Cold Water Temperature Regulation Hot Water Circulation
  • Load image into Gallery viewer, Thermostatic Mixing Valve Nickel DN20/DN25 Hot And Cold Water Temperature Regulation Hot Water Circulation
  • Load image into Gallery viewer, Thermostatic Mixing Valve Nickel DN20/DN25 Hot And Cold Water Temperature Regulation Hot Water Circulation
  • Load image into Gallery viewer, Thermostatic Mixing Valve Nickel DN20/DN25 Hot And Cold Water Temperature Regulation Hot Water Circulation

Thermostatic Mixing Valve Nickel DN20/DN25 Hot And Cold Water Temperature Regulation Hot Water Circulation

Regular price
$38.99
Sale price
$38.99
Regular price
Sold out
Unit price
per
Shipping calculated at checkout.

Specifications
◎Working Temperature Range: 35 ~ 60°C (95 ~ 140℉)
◎Max Working Temperature: 95°C (203℉), Short Time: 110°C (230℉)
◎Accuracy of Outlet Mixing: ±2°C (35.6℉)
◎Reference Hot And Cold Pressure: 3bar
◎Max Static Pressure: 10bar
◎Max Working Pressure: 5bar
◎Max Difference Between Inlet Pressures: 3bar
◎Flow: 1.6-2.5m3/h
◎Fluid: Sanitary Water, Water/Glycol Solution Max 30%
◎Valve Body: CW617N
◎Handle: Nylone
◎Gasket: EPDM

Features
◎Built-in check valve;
◎Suitable for household hot water installations equipped with HWC (hot water circulation) or underfloor heating;
